8-Port Lite-Managed Slim Switch,Micro-SD
| Switch Properties |
|
| Priority Queues |
8 |
| VLAN Table |
4096 |
| Trunk Group |
4 |
| MAC Table Size |
16K |
| Packet Buffer Size |
1 Mb |
| Jumbo Frame |
1664 Byte |
| Ethernet Interfaces |
|
| Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-T(X)
IEEE 802.3x for Flow Control, back pressure flow control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1q for VLAN tagging
IEEE 802.1AB for LLDP protocol
Auto MDI/MDI-X |
| Protocols |
IPv4, SNMP v1/2/3, SNMP trap, RMON History, LLDP, Syslog,
HTTPs, DHCP client, NTP, SNTP, VLAN |
| Redundancy |
STP, RSTP |
| SNMP MIB |
RFC1213, Ethernet-like MIB, IF MIB, LLDP MIB,
Bridge MIB |
| RJ-45 |
Up to 8 |
| Connector Type |
USB x 1 or Micro-SD card x1 |
| LED Indicators |
PWR1, PWR2, ALM, LAN, Ring, Run |
| Power |
|
| Input Voltage |
12 – 48 VDC |
| Power Consumption |
6W |
| Power Redundancy |
DC |
| Reverse Polarity Protection |
Yes |
| Physical Characteristics |
|
| Housing |
IP30 protection, SGCC, Black |
| Dimension (W x H x D mm) |
25.4 x 140 x 112 |
| Installation |
DIN-Rail, Wall mount (optional kit) |
| Reset Button |
Yes |
| Environmental Limits |
|
| Operating Temperature |
-40°C to +75°C (-40°F to +158°F)
or -10°C to +60°C (-14°F to 140°F) |
| Storage Temperature |
40°C to +85°C (-40°F to +185°F) |
| Ambient Relative Humidity |
5% to 95%, 55°C (Non-condensing) |
