Embedded device server for TTL devices, drop-in module, up to 230.4Kbps, without RJ45, 0 to 55C
Input/Output Interface
-
Configurable DIO Channels (by software)
Ethernet Interface
-
10/100BaseT(X) Ports, Auto MDI/MDI-X
-
Magnetic Isolation Protection
Ethernet Software Features
-
Configuration Options
- Web Console (HTTP), Windows Utility
-
Management
- ARP, BOOTP, Device Search Utility (DSU), DHCP Client, IPv4, SMTP, SNMPv1, TCP/IP, Telnet, TFTP, UDP, ICMP
-
Windows Real COM Drivers
- Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
-
Linux Real TTY Drivers
- Kernel versions: 2.4.x, 2.6.x, 3.x, 4.x, and 5.x
-
Fixed TTY Drivers
- SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
-
Android API
Serial Interface
-
No. of Ports
-
Serial Standards
-
Operation Modes
- Real COM mode, RFC2217 mode, TCP Client mode, TCP Server mode, UDP mode, Ethernet Modem mode, MCSC mode
-
Baudrate
-
Data Bits
-
Stop Bits
-
Parity
- None, Even, Odd, Space, Mark
-
Flow Control
- None, RTS/CTS, DTR/DSR, XON/XOFF
Serial Signals
-
TTL
- • TxD, RxD, RTS, CTS, DTR, DSR, DCD, RST (reset circuit), GND
NetEZ Technology
-
NetEZ Functions
- EZPower, EZPage, SCM (Serial Command Mode), AutoCFG, MCSC (Multi-Channel Serial Communication)
Power Parameters
-
Input Current
-
Input Voltage
Physical Characteristics
-
Dimensions
- 29 x 17 x 12.6 mm (1.14 x 0.67 x 0.50 in)
-
Weight
-
Form Factor Type
Environmental Limits
-
Operating Temperature
-
Storage Temperature (package included)
- -40 to 60°C (-40 to 140°F)
-
Ambient Relative Humidity
- 5 to 95% (non-condensing)
Standards and Certifications
-
EMS
- IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 0.5 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11 DIPs
-
Environmental Testing
- IEC 60068-2-1
IEC 60068-2-3
-
EMC
-
EMI
- CISPR 32, FCC Part 15B Class B
-
Shock
-
Vibration
