The ICS-R373 series features a cost-effective embedded system incorporating an Intel® Atom® C3000 series CPU, housed in an IP40 rated fanless enclosure. This industrial computer delivers high-quality performance with low power consumption, catering to Industrial Cybersecurity and Flexible SDWAN applications across various sectors such as Vehicle, Railway, and Power Substation Security. The product serves as a system monitor for industrial cybersecurity, supporting a power input range of DC 24-110V within an operational temperature range of -40oC ~ 70oC. Certified with standards including MIL-STD-810G, EN 50125-3, EN50124-1, UL/IEC 62368-1, EN 50155, EN 50121-3-2, EN 50121-4, EN 45545-2, IEC-61850-3, IEEE 1613, and more, the ICS-R373 series ensures robust and reliable performance across diverse applications, as indicated by SKU variations.
| Processor System | |
| CPU | Intel® Atom® C3708/C3508/C3308 (Denverton) |
| Frequency | 1.7 GHz/1.6 GHz/1.6 GHz |
| Core Number | 8/4/2 |
| BIOS | AMI SPI Flash BIOS |
| Chipset | SoC |
| Fanless | |
| Yes | |
| Memory | |
| Technology | 1/ 2x DDR4 SODIMM w ECC/ non-ECC up to 2133/1866Mhz |
| Max. Capacity | 64GB/32GB (By SKU) |
| Ethernet | |
| Controller | Intel® i226IT & MARVELL_88E1548 |
| Speed | 10/100/1000 Mbps |
| Protection | 1.5KV Isolation Protection |
| Interface | 4x GbE RJ45, 2x 2.5GbE RJ45 |
| Bypass | 1 pair Gen3 for 2.5GbE (By SKU A) |
| Storage | |
| Type | SATA |
| Installation | 1x M.2 2242/2280 M-Key |
| Type | eMMC |
| Installation | Onboard eMMC 128GB/32GB TLC (By SKU) |
| I/O | |
| GPS | u-blox NEO-M9V/SL869L-V2 (By SKU); 4 GNSS (BeiDou, Galileo, GLONASS, GPS/QZSS), Default GPS + GLONASS Dual Band |
| G-sensor | Include in GPS Module |
| USB | 2x USB 2.0 Type A |
| OOB | 1x RJ45 OOB (By SKU A) |
| Reset Button | 1x Reset Button |
| Antenna | 11x SMA Antenna Hole, Includes 1x 4 Concurrent GNSS (BeiDou, Galileo, GLONASS, GPS / QZSS) |
| Expansion | |
| M.2 | 1x M.2 2230 E-Key for WiFi 2x M.2 3042/3050/3052 B-Key for LTE/5G |
| Power | |
| Input | 24~110VDC |
| Connector | 2x 3-pin terminal block (+,-,ignition) |
| Power Consumption (Idle) | 28.72W (A); 23.22W (B); 21.22W (C) |
| Power Consumption (Full Load) | 35.28W (A); 29.78W (B); 27.78W (C) |
| Cooling | |
| Processor | Passive CPU heatsink |
| System | IP40/Fanless System (optional IP51 KIT) |
| Environment | |
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F |
| Storage Temperature | -40°C ~ 85°C / -40°F ~ 185°F |
| Relative Humidity | 5%~90% Operating; 5~95% Non-Operating |
| Miscellaneous | |
| Watchdog | Yes |
| Internal RTC with Li Battery | Yes |
| TPM | Onboard TPM 2.0 |
| Mechanical | |
| Dimension (W x D x H) | 280 x 196 x 83 mm |
| Packaging Dimension | 379 x 300 x 191 (inner) |
| Protection Class | IP40 / option IP51 |
| Weight | 4.2 kg |
| Mounting | Wall mount kit (optional DIN Rail/VESA mount) |
| Driver Support | |
| Microsoft Windows | Dabian 10 pre-installed, Win 10 IoT |
| Certification | |
| EMC | E13, CE Class A, FCC Class A, RoHS |
| Certified | MIL-STD-810G, EN 50125-3, EN 50124-1 |
| Compliance | C1D2 (By SKU A), UL/IEC 62368-1, EN 50155, EN 50121-3-2, EN 50121-4, EN 45545-2, IEC-61850-3, IEEE 1613 |
| ICS-R373A | Intel Atom™ C3708 Processor, DDR4 non-ECC 16GB, eMMC 128GB ,4x GbE RJ45, 2x 2.5GbE RJ45 w bypass, TPM2.0, GPS, OOB, DC 24-110V w Ignition power input |
| ICS-R373B | Intel Atom™ C3508 Processor, DDR4 non-ECC 8GB, eMMC 32GB ,4x GbE RJ45, 2x 2.5GbE RJ45, TPM2.0, GPS, OOB, DC 24-110V w Ignition power input |
| ICS-R373C | Intel Atom™ C3308 Processor, DDR4 non-ECC 4GB, eMMC 32GB ,4x GbE RJ45, TPM2.0, GPS, DC 24-110V w Ignition power input |
