Simplifying System Expansion

Upgrading or implementing new surveillance systems can be a difficult process. With Innodisk's Power over Ethernet (PoE) expansion cards the system can readily handle power and data signal running through the same wiring; drastically simplifying your implementation and also saving costs.

Product Highlights

ESPL-G4P1

ESPL-G4P1

PCIe to four isolated PoE/PoE+ Module

  • Supports four GbE LAN ports
  • Four independent PSE channels
  • Complies with IEEE 802.3af, up to 15.4W at 48V per PoE port
  • Complies with IEEE 802.3at, up to 25.5W at 52V per PoE port
  • Supports 12V~24V power input via 6pin PCIE-ATX
  • Supplies total power up to 75W
  • Complies with EN61000-4-5 2kV Surge protection
  • 30μ golden finger, 3 years warranty

EMPL-G2P2

EMPL-G2P2

mPCIe to dual isolated PoE+ Module

  • Supports dual GbE LAN ports
  • Two independent PSE channels
  • Supports 19V~24V (±5%) power input via 4pin header
  • Complies with IEEE 802.3at, up to 25.5W at 52V per PoE port.
  • Complies with EN61000-4-2 (ESD) Air-15kV, Contact- 8kV
  • Industrial temperature -40 ºC to 85 ºC

Mid-Atlantic Rugged Systems is your Authorized Innodisk Distributor

Contact Us:

sales@marugged.com

855-784-4334
