Progressive Accelerator for Intelligent Edge | M/A Rugged

Next-generation Performance

• The latest 13th Gen Intel Core i9/i7/i5/i3 processor running with Intel R680E PCH (codename Raptor Lake-S), up to 24 cores and 32 threads with advanced performance hybrid architecture, up to 65W CPU supported
• Supports up to 4% faster single-thread performance and up to 34% faster multithread performance vs. 12th Gen Intel Core processors
• Intel UHD Graphics 770 driven by Intel Xe Architecture with up to 32 graphics execution units (EUs) supporting immersive interactions with integrated graphics and accelerated AI, with up to 1.25x faster in CPU image classification inference performance
• High-speed data transfer : PCIe 4.0 (16GT/s), USB 3.2 Gen 2x2 Type-C (20G), 10GigE LAN (10G), SATA III (6G), 2.5GigE LAN (2.5G), GigE LAN (1G)

ECX-3200/3100(M12) : Compact Flexible Rugged Operation

• The latest 13th Gen Intel Core i9/i7/i5/i3 processor running with Intel R680E PCH (codename Raptor Lake-S), up to 65W CPU supported
• Dual DDR5 4800MHz SO-DIMM, up to 64GB Memory
• Fanless -40°C to 75°C Operation
• Max 4 Independent X-coded M12 2.5G IEEE 802.3at PoE+ LAN
• 2 Front-access 2.5” SSD Tray, 6 USB 3.2 Gen 2
• USB 3.2 Gen 2x2 offers a max speed of 20Gbps data transfer
• PCIe x16 slot for 10GigE/2.5GigE/GigE/LAN Switch/USB features
• DC 9V to 50V Power Input, Software Ignition Control
• Smart Management : Intel® vPro, TCC, TSN, TPM 2.0, PXE, Wake on LAN, Remote Power Switch
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

• The latest 13th Gen Intel Core i9/i7/i5/i3 processor running with Intel R680E PCH (codename Raptor Lake-S), up to 65W CPU supported
• Dual DDR5 4800MHz SO-DIMM, up to 64GB Memory
• Supports performance hybrid architecture and advanced AI capabilities for smarter and faster applications via low-profile Discrete Graphics Card or AI Accelerators
• Max 4 Independent 2.5G IEEE 802.3at PoE+ LAN, X-coded M12
• Max 4 Front-access 2.5” SSD Tray, 6 USB 3.2 Gen 2
• USB 3.2 Gen 2x2 offers a max speed of 20Gbps data transfer
• Versatile PCIe x16, PCIe x8, PCIe x4 Configurations
• DC 12V to 50V Power Input, Software Ignition Control
• Smart Management : Intel® vPro, TCC, TSN, TPM 2.0, PXE, Wake on LAN, Remote Power Switch
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

• The latest 13th Gen Intel Core i9/i7/i5/i3 processor running with Intel R680E PCH (codename Raptor Lake-S) supports performance hybrid architecture and advanced AI capabilities smarter and faster applications
• Dual DDR5 4800MHz SO-DIMM, up to 64GB Memory
• Optional supports outstanding AI computing productivity by advanced and compact MXM graphics card
• DC 16V to 160V Power Input with 4kV Isolation, up to 500V Surge Protection, Software Ignition Control, optional UPS supported
• Rugged designs for Rolling Stock applications, fully comply with EN50155 : 2017 and EN45545-2
• 8 Independent 2.5GigE X-coded M12 LAN with 4 IEEE 802.3at PoE+
• 6 Front-access and lockable 7mm to 15mm height SSD/HDD Tray, max 24TB capacity, RAID 0, 1, 5, 10 Data Protection
• Smart Management : Intel® vPro, TCC, TSN, TPM 2.0, PXE, Wake on LAN, Remote Power Switch
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications
